overview

High-Quality Plastic Injection Mold Services tailored to meet the specific needs of our clients.

At Sequel Tool and Mold, we specialize in providing high-quality plastic injection mold services tailored to meet the specific needs of our clients. Our expertise in designing, engineering, and manufacturing molds for various industries ensures precision, durability, and cost-efficiency. Utilizing advanced technology and a customer-focused approach, we deliver molds that perform reliably under the most demanding conditions.

If you seek exceptional quality, precise construction, and rigorous quality control for your plastic injection molding projects, Sequel Tool and Mold is your ideal partner. From concept to completion, we cover all aspects of your injection molding needs, ensuring that each project is executed with the highest level of expertise and attention to detail.

Our comprehensive injection assembly services are designed to ensure that every custom plastic part we produce meets your specific requirements and tolerances. From initial concept to the final product, we follow a meticulous process that includes:

Material Selection

Helping you choose the best materials for your application to achieve the desired balance of durability, flexibility, and cost-effectiveness.

Design Consultation

Collaborating with you to understand your needs and provide design recommendations that optimize performance and manufacturability.

Tooling and Mold Construction

Utilizing advanced technologies and high-quality materials to create molds that ensure precision and repeatability in every production run.

Production and Quality Control

Conducting rigorous testing and inspection throughout the manufacturing process to maintain the highest quality standards and ensure that every part meets your specifications.

At Sequel Tool and Mold, we believe that collaboration is key to success. That’s why we involve our clients at every stage of their custom plastic injection molding project. Our client-centered approach to project management ensures that you are engaged throughout the process, from the initial design phase through to prototype development and final production.

SXKH

Suquel conveniently match all the parts of the mold in more comfortable position with SXKH HMG-350ES2520. We check and finish the die at one place in more ergonomic position. This highly flexible and cost-effective machine also allows us to access the molds easily.

Specs

Max. Mold Clamping Force: 3,000 KN
Max. Lifting Power 700 KN
Upper Table Load Capacity: 22,000 Kg
Lower Table Load Capacity: 43,000 Kg
Working Table Size: 2,500 x 2000 mm
Distance between Pillars: 2,300 mm
Max. Daylight: 2,500 mm
Min. Daylight: 400 mm
Overturn Degree: None
High Down Stroke Speed: 50-80 mm/s
Low Down Stroke Speed: 8 mm/s
Motor Power: 30 KW

Machine Size: 6000 x 3000 x 7000 mm
Weight: 61,000 kg

Dake

Sequel utilizes Die Spotting Press with Dake Press 18-389 with a capacity of 100 tons and 43 tons of up stroke. It uses 15 horsepower and 1800 RPM. This press has 3 separate functions - Press, Bolster and Pins. No function can operate simultaneously with each of the other two.

Specs

Maximum Capacity: 100 Ton
Up Stroke: 43 Tons
Power: 15 H.P
RPM: 1,800
Mold Space: 48" Front to Back x 72" Left to Right
Daylight Opening: 60" / 40" stroke

Max. Dimensions: 123" x 177" x 190"
Approx. Weight: 42, 934 lbs.

Sequel Tool and Mold Inc. is here to help you.

Whether you are developing a new product, or want to improve an existing one.

services

Our experience can guide you through each stage

Added many years of industry experience, our team is well-equipped to guide you through each stage of the manufacturing process. We are committed to delivering your product on time and within budget, ensuring a seamless experience from start to finish.
